THORLED 24W IP67 6500K IP67 230V 3310300

Description VT/THORLED/24W/65K/IP67/PC/2x65CM/220V/WPROOF LAMP
Stock Code 3310300
Main Group Luminaires
Sub Group
Structure with Lightsource
Operation Type Ready to Operate
Mounting Type Other
HSC/GTIP Code 9405.10.40.90.00
Electrical Characteristics
Current Type AC
Operation Voltage 170-265 Volt
Operation Frequency 50/60 Hertz
Electrical Current 0,8 Amper
Power 24 Watt
Power Factor >0.9
Luminous Efficiency 100 lumen/Watt
Energy Savings 0,84
Weighted Energy Consumption 24 kWh/1000h
Dimmable No
Electrical Protection Class Class II
Electrical Efficiency Index (EEI) A+
Electrical Component Specifications
Component Fitting Type Internal Driver
Driver Properties non-Isolated
Driver Input Voltage 80-265 Volt
Driver Input Voltage 80-265 Volt
Driver Input Current 0,8 Amper
Lighting Characteristics
CCT 6500K
Luminous Flux 2400 lumen
Time for 60% of Lumen <0.5 seconds Color Rendering Index (CRI) >80
Light Beam Angle 120°
Flicker No
LED Type SMD 2835
LED Chip Brand Sanan
LED Quantity 144 pieces
Mechanical Parameters
Fixture Shape Linear
IP Protection Class IP67
IP Protection Class IP67
Switch On/Off Cycle 30000
Lifetime 25000 hours
Body Material Plastic
Body Colour White
Diffuser Material PC
Product Height 82 milimeter
Product Width 650 milimeter
Product Depth 37 milimeter
Ambient Temperature (Ta) -20°C
