THORLED-V60 18W IP67 4000K IP65 230V 3310510

Description VT/THORLED-V60/18W/40K/IP67/220V/WATERPROOF LAMP
Stock Code 3310510
Main Group Luminaires
Sub Group
Structure with Lightsource
Operation Type Ready to Operate
Mounting Type Other
HSC/GTIP Code 9405.10.40.90.00
Electrical Characteristics
Current Type AC
Operation Voltage 170-265 Volt
Operation Frequency 50/60 Hertz
Electrical Current 0,09 Amper
Power 18 Watt
Power Factor >0.5
Luminous Efficiency 85 lumen/Watt
Energy Savings 0,82
Weighted Energy Consumption 18 kWh/1000h
Dimmable No
Electrical Protection Class Class II
Electrical Efficiency Index (EEI) A+
Electrical Component Specifications
Component Fitting Type Internal Driver
Driver Properties non-Isolated
Driver Input Voltage 170-265 Volt
Driver Input Current 0,09 Amper
Lighting Characteristics
CCT 4000K
Luminous Flux 1530 lumen
Time for 60% of Lumen <0.5 seconds Color Rendering Index (CRI) >80
Light Beam Angle 120°
Flicker No
LED Type SMD
LED Chip Brand Sanan
Mechanical Parameters
Fixture Shape Linear
IP Protection Class IP65
Switch On/Off Cycle 30000
Lifetime 25000 hours
Body Material Plastic & Aluminum
Body Colour White
Diffuser Material PC
Product Height 36 milimeter
Product Width 568 milimeter
Product Depth 78 milimeter
Ambient Temperature (Ta) -20°C
